SHB
The functional base layer of the SHBC two-part system. System component 1.
SHBC
Two-layer superhydrophobic coating system
SHBC is a white, opaque and flexible two-layer system that combines the SHB base coat with the SHC finishing coat for extreme liquid repellency.
- Application
- Pressurized spraying
- Curing
- Room temperature, High temperature
- Packaging
- 1 L · 5 L · 20 L
- Surfaces
- Metal, painted, composite and other prepared industrial surfaces requiring extreme water repellency.
What the surface gains.
On the surface
- Opaque, flexible coating
- Superhydrophobicity
- Oleophobicity
In use
- UV protection
- Dirt repellency
- Easy clean
- Anti-icing
Over time
- Extends surface lifetime
- Saves maintenance cost
- Reduces fungal growth and darkening
- Reduces icing
Technical data.
| Property | SHBC |
|---|---|
| Appearance | Whitish liquid |
| Saltwater resistance | Yes |
| Dry film thickness | 8-10 µm |
| Consumption per unit area | 80-100 mL/m² |
| Breathability (EN 1062-1) | Category 1 |
| pH value | SHB: 5.0-5.3; SHC: 4.7-5.0 |
| Application temperature | 5°C-30°C (≤50% RH) |
| Temperature durability | 175°C |
| Water contact angle | 171° @10 µL |
| Water sliding angle | 1° @60 µL |
| Oil contact angle | 140° @10 µL |
| Shelf life | 1 year unopened; 1 month after opening |
| Durability | Up to 2 years without abrasion |
Formulations.
2 options in the SHBC system.
Match the coating
to the job.
Share the substrate, environment and required performance. We’ll help confirm the right formulation and application process.
